MacGregor guide pins

MacGregor guide pins are of simple, strong construction. They are type-approved by ABS and DNV and have been designed according to Norwegian Maritime Directorate regulations (NMD 48).

MacGregor guide pins are standard equipment for many key operators in the industry. When both guide pins are raised they close completely together at the top for maximum security.

MacGregor S-type guide pins:

• The angular nature of MacGregor S-type guide pins removes the need for an extra locking mechanism on top of the pins.
• They have a simple design and durable construction, with large diameter rotating rollers with bronze bearings.
• They meet the NMD requirements both for sideways (60°) and upwards (30°) movement under maximum load.

Models:

• S-65 SWL 65 tonnes
• S-115 SWL 115 tonnes
• S-200 SWL 200 tonnes
• S-300 SWL 300 tonnes

MacGregor V-type guide pins:

High-quality steel rotating rollers are mounted on bronze bearings.

• The vertical guide pins have a hydraulic locking device on top.
• They meet the NMD requirements both for sideways (60°) and upwards (30°) movement under maximum load.

Models:

• V-200 SWL200 tonnes
• V-300 SWL300 tonnes
• V-300-H SWL300 tonnes (extended height)
